Transmission Lip Seals
The Integrated Sealing Solutions’ molded lip seals are cost effective seals, designed to maximize seal force while providing outstanding drag characteristics in dynamic applications. The customized seal shape and proven molded technology provides an outstanding static or dynamic seal, as required in your application. Our lip seal designs conform to cylinder wall irregularities and provide more sealing surface than a standard seal. Typical sizes range from 0.750 to 25 inches in diameter.
We offer a large selection of standard materials, and we can formulate custom materials to meet your specific needs.
Product Highlights:
- Easy installation
- Low drag
- Customized cross-sections
Product Features:
- Easy installation
- Low drag
- Customized cross-sections
- Conforms to cylinder wall irregularities
- Reduced hydraulic pass-by
- Self energized
Benefits:
- Low cost
- Minimal tooling cost
- Long tool life
- Proven design
As can be seen from the Finite Element Analysis (FEA) results, a radial lip seal produces about 1/10 of the radial load of a D-ring with the same amount of radial squeeze. In dynamic applications, this gives the lip seal a distinct advantage in allowing the piston to move with lower pressure requirements than might be needed for other seals. Also, lip seals do not have a parting line at the sealing location. Therefore eliminating the application concerns about the quality of the parting line and the amount of frictional drag. O-ring or D-ring do have a distinct advantage in static applications where frictional drag is of no concern.
